The Types Of AC Power Socket Supply

AC power sockets are the standard means through which we connect to the electrical grid to power electronic devices. There are different types of these sockets used in different parts of the world, with variations in shape, size, voltage, and current rating. In this post, we will look at some of the most common types of AC power sockets you will come across.

1. Type A

This is the standard socket used in North America, Central America, and some parts of South America and the Caribbean. It has two flat parallel pins with an optional grounding pin in the middle. It is rated for 15A or 20A, and the voltage is 120V AC at 60Hz. The Type A plug is also used in Japan, but the voltage is typically 100V AC.

2. Type B

The Type B socket is similar in design to the Type A, but it has an additional grounding pin that is round and protrudes from the bottom of the plug. This type of socket is used in North America, Central America, and some parts of South America and the Caribbean. It is also rated for 15A or 20A, and its voltage is 120V AC at 60Hz.

3. Type C

This socket is the most commonly used socket in Europe, Asia, Africa, and South America. It has two round pins that are 19mm apart and no grounding pin. The Type C socket is rated for 2.5A or 5A and has a voltage of 220V AC at 50Hz. It is used in countries such as France, Italy, Spain, and Portugal.

4. Type D

The Type D socket is commonly used in India, Sri Lanka, and Nepal. It has three round pins in a triangular pattern and is rated for 5A or 15A. The voltage is typically 220-240V AC at 50Hz. The Type D socket is also sometimes called the “Indian plug” or “BS-546.”

5. Type E

The Type E socket is commonly used in France, Belgium, and some parts of Africa. It has two round pins spaced 19mm apart, and an additional grounding pin that is cylindrical and 4mm in diameter. The Type E socket is rated for 16A and has a voltage of 220-240V AC at 50Hz.

6. Type F

The Type F socket is used in most parts of Europe, and it is similar in design to the Type E socket. It has two round pins spaced 19mm apart and an additional grounding pin that is 4.8mm in diameter. The Type F socket is rated for 16A and has a voltage of 220-240V AC at 50Hz.

7. Type G

The Type G socket is commonly used in the United Kingdom, Ireland, and some parts of Africa and Asia. It has three rectangular pins in triangular pattern and an optional grounding pin on the plug. The Type G socket is rated for 13A, and the voltage is 230V AC at 50Hz.

8. Type H

The Type H socket is the standard socket used in Israel, and it is also used in some African countries. It has three round pins in a triangular pattern and is rated for 16A. The voltage is 220-240V AC at 50Hz.

9. Type I

The Type I socket is used in Australia, New Zealand, Papua New Guinea, and some parts of Asia. It has two flat slanted pins and an additional grounding pin that is angled. The Type I socket is rated for 10A or 15A, and the voltage is typically 220-240V AC at 50Hz.

10. Type J

The Type J socket is used in Switzerland and Liechtenstein, and it has three round pins in a triangular pattern. The grounding pin is shorter than the two other pins. The Type J socket is rated for 10A or 16A, and the voltage is 220-240V AC at 50Hz.

In conclusion, AC power sockets vary in shape, size, voltage, and current rating, depending on the region in which they are used. It is important to be aware of the differences when traveling to ensure that your electronic devices can be plugged in and operated safely.
