Right Angle Toggle Switch

A mini toggle switch is a small but extremely versatile component that is often used in electronic circuits. The purpose of the switch is to allow the user to control the electrical current flowing through a device, which can be useful for turning devices on and off, adjusting the volume or tone of an audio signal, or selecting different modes of operation in a complex electronic device.

One common type of mini toggle switch is the right-angle 3-pin mini toggle switch. This type of switch is designed to be mounted onto a printed circuit board (PCB) and features three pins that allow the switch to be connected into an electronic circuit.

In this article, we will take a closer look at the right-angle 3-pin mini toggle switch and explore its features, applications, and benefits.

Features of the Right-Angle 3-Pin Mini Toggle Switch

The right-angle 3-pin mini toggle switch is a small component that measures just a few millimeters in size. Despite its small size, the switch is designed to be durable and long-lasting, allowing it to withstand the wear and tear of daily use.

The switch features a plastic or metal body that houses the three pins. The pins are mounted at a right angle to the switch body, which allows the switch to be mounted onto a PCB in a space-saving configuration.

The switch itself operates by means of a lever that is attached to an internal mechanism. When the lever is moved from one position to another, the internal mechanism changes the flow of current through the switch, allowing the user to control the function of the device that the switch is connected to

PRODUCT DIMENSION

PRODUCT CATEGORY

Tactile switches, button switches, toggle switches, rocker switches, slide switches, microswitches, sockets and connectors, as well as hardware stamping and plastic injection.

aPPLICATIONS

Applications of Subminiature Toggle Switches

Subminiature toggle switches are used in different electronic devices and circuits. They are particularly useful in applications where small size and low voltage and current are required. Here are some of the common applications:

1. Portable electronic devices

Subminiature toggle switches are ideal for use in portable electronic devices that require small switches. These devices include small-sized radios, calculators, and other small electronic gadgets.

2. Amplifiers

Subminiature toggle switches are also used in small electronic amplifiers that require low voltage and current. These amplifiers are commonly used in small speakers, headphones, and other audio devices.

3. Automotive applications

Subminiature toggle switches can be used in automotive applications such as dashboards, interior lights, and other electronic circuits in cars.

4. Industrial applications

Subminiature toggle switches are used in different industrial applications where small size and low voltage and current are required. These applications include control boxes, small machines, and other electronic circuits.
